Stream Filtering Guide

Overview

Hyperliquid streaming APIs support powerful filtering capabilities to help you receive only the data you need. Filters work across gRPC, JSON-RPC, and WebSocket protocols, allowing you to subscribe to specific events, users, trading pairs, and more.

Supported Protocols:

gRPC Streaming API - High-performance streaming with filters
JSON-RPC over WebSocket - Standard WebSocket filtering
WebSocket API - Real-time filtered subscriptions

Why Use Filtering?

Without filtering, streaming from Hyperliquid can generate massive amounts of data. The exchange processes thousands of trades, orders, and events per minute across hundreds of trading pairs. Filtering is essential because it allows you to:

Reduce bandwidth and improve performance - Receive only relevant data instead of processing everything, significantly reducing network traffic and processing overhead
Focus on specific data - Track particular trading pairs, users, or event types instead of consuming all market data
Build efficient applications - Create focused applications without overwhelming data streams that could impact performance
Enable real-time decision making - Process targeted data faster for alerts, notifications, and trading decisions

Basic Filtering Concepts

Before diving into syntax, here are the key concepts:

Streams - Different data types (trades, orders, events, etc.)
Fields - Properties within each stream that can be filtered
Values - Specific criteria you want to match
Logic - How multiple filters combine (AND/OR)

Simple Example:

"I want to see only BTC trades that are buys (not sells)"

WebSocket Filter: {"coin": ["BTC"], "side": ["B"]}
gRPC Filter: {"coin": {"values": ["BTC"]}, "side": {"values": ["B"]}}

Available Streams

Stream Name	Description	Data Format
trades	Filled trades/executions	Tuple: [user_address, fill_data]
orders	Order status updates	Object with order fields
book_updates	Order book changes	Object with price/size
twap_orders	TWAP order statuses	Flexible object
events	Ledger updates, deposits, withdrawals, funding	Nested object
writer_actions	System actions, spot sends	Object with action type
mempool_txs	Pending mempool transactions (gRPC only, testnet only)	Tuple: [timestamp, transaction_data]
blocks	Raw replica commands (gRPC only, NO FILTERING)	Full block data
StreamL2Book	Aggregated price levels (gRPC only - coin specified in request)	L2BookUpdate protobuf
StreamL4Book	Individual orders (gRPC only - coin specified in request)	L4BookUpdate protobuf

Filter Syntax

WebSocket and gRPC APIs use similar filter logic, but with different syntax:

WebSocket (JSON-RPC)
gRPC

{
  "jsonrpc": "2.0",
  "method": "hl_subscribe",
  "params": {
    "streamType": "trades",
    "filters": {
      "<field_name>": ["<value1>", "<value2>"]
    },
    "filterName": "optional_name"
  },
  "id": 1
}

Key points:

streamType: Stream name (trades, events, etc.)
filters: Each field maps directly to an array of values
filterName: Optional name for this filter (enables OR logic, unsubscribe by name)
Multiple streams require separate subscription requests

Subscribe {
  stream_type: <STREAM_TYPE_ENUM>,
  filters: {
    "<field_name>": FilterValues { values: ["<value1>", "<value2>"] }
  }
}

Filter Logic

AND Across Fields

When multiple fields are specified, ALL must match:

// WebSocket
{"filters": {"coin": ["BTC"], "side": ["B"]}}

Returns events where coin=BTC AND side=B

OR Within Field

When multiple values are specified for one field, ANY can match:

// WebSocket
{"filters": {"coin": ["BTC", "ETH", "HYPE"]}}

Returns events where coin=BTC OR coin=ETH OR coin=HYPE

Combined Example

// WebSocket
{"filters": {"coin": ["BTC", "ETH"], "side": ["B"]}}

Returns events where (coin=BTC OR coin=ETH) AND side=B

OR Across Named Filters (Advanced)

Multiple subscriptions with different filterName values on the same stream = OR logic between them.

Request 1:

{
  "jsonrpc": "2.0",
  "method": "hl_subscribe",
  "params": {
    "streamType": "trades",
    "filters": {
      "coin": ["BTC"],
      "side": ["B"]
    },
    "filterName": "btc_buys"
  },
  "id": 1
}

Request 2:

{
  "jsonrpc": "2.0",
  "method": "hl_subscribe",
  "params": {
    "streamType": "trades",
    "filters": {
      "coin": ["ETH"],
      "side": ["A"]
    },
    "filterName": "eth_sells"
  },
  "id": 2
}

Returns (BTC AND side=B) OR (ETH AND side=A)

This is impossible with a single filter since AND applies across all fields.

Recursive Field Matching

Filters automatically search through nested JSON objects:

// This data:
{"inner": {"LedgerUpdate": {"users": ["0xABC"], "delta": {"type": "deposit"}}}}

// Matches this WebSocket filter:
{"filters": {"type": ["deposit"]}}

Special Filter Values

Value	Meaning	Use Case
"*"	Field exists (any value)	Find all liquidations: {"liquidation": {"values": ["*"]}}
"exists"	Same as "*"	Alternative syntax: {"liquidation": {"values": ["exists"]}}
"null"	Field is null	Find unfilled TWAPs: {"twapId": {"values": ["null"]}}

Existence Filter Examples

// Find all trades that are liquidations (WebSocket)
{"filters": {"liquidation": ["*"]}}

// Find all trades with a builder (WebSocket)
{"filters": {"builder": ["*"]}}

// Find trades without TWAP ID (WebSocket)
{"filters": {"twapId": ["null"]}}

Stream-Specific Fields

Trades Stream

Filter completed trades and fills by user, trading pair, side, price, and execution details.

Format: Each event is a tuple [user_address, fill_data]

Field	Type	Description	Example Filter
user	string	Wallet address (matches tuple first element)	{"user": {"values": ["0x123..."]}}
coin	string	Trading pair	{"coin": {"values": ["BTC", "ETH"]}}
side	string	"A" (ask/sell) or "B" (bid/buy)	{"side": {"values": ["B"]}}
px	string	Execution price	{"px": {"values": ["50000"]}}
sz	string	Size executed	-
dir	string	Direction	{"dir": {"values": ["Open Long", "Close Short"]}}
crossed	boolean	Crossed the spread	{"crossed": {"values": ["true"]}}
fee	string	Fee amount	-
feeToken	string	Fee token	{"feeToken": {"values": ["USDC"]}}
hash	string	Transaction hash	{"hash": {"values": ["0xabc..."]}}
oid	number	Order ID	{"oid": {"values": ["12345"]}}
tid	number	Trade ID	-
cloid	string	Client order ID (optional)	{"cloid": {"values": ["0x..."]}}
twapId	number/null	TWAP ID if from TWAP	{"twapId": {"values": ["*"]}}
builder	string	Builder address (optional)	{"builder": {"values": ["0x999..."]}}
builderFee	string	Builder fee (optional)	-
liquidation	object	Liquidation data (optional)	{"liquidation": {"values": ["*"]}}
liquidation.liquidatedUser	string	Liquidated user address	{"liquidatedUser": {"values": ["0x..."]}}
liquidation.method	string	Liquidation method	{"method": {"values": ["market"]}}
liquidation.markPx	string	Mark price at liquidation	-

Trades Filter Examples

// Get all BTC buys (WebSocket)
{"streamType": "trades", "filters": {"coin": ["BTC"], "side": ["B"]}}

// Get liquidations only (WebSocket)
{"streamType": "trades", "filters": {"liquidation": ["*"]}}

// Get trades for specific user (WebSocket)
{"streamType": "trades", "filters": {"user": ["0x727956612a8700627451204a3ae26268bd1a1525"]}}

// Get TWAP executions only (WebSocket)
{"streamType": "trades", "filters": {"twapId": ["*"]}}

Orders Stream

Monitor order status updates including placements, cancellations, and partial fills.

Field	Type	Description	Example Filter
coin	string	Trading pair	{"coin": {"values": ["ETH"]}}
side	string	"A" or "B"	{"side": {"values": ["A"]}}
limit_px	string	Limit price	-
sz	string	Current size	-
orig_sz	string	Original size	-
oid	number	Order ID	{"oid": {"values": ["12345"]}}
timestamp	number	Order timestamp	-

Orders Filter Examples

// Get all ETH orders (WebSocket)
{"streamType": "orders", "filters": {"coin": ["ETH"]}}

// Get sell orders only (WebSocket)
{"streamType": "orders", "filters": {"side": ["A"]}}

Book Updates Stream

Track order book changes including price level updates and size modifications for bid and ask sides.

Field	Type	Description	Example Filter
coin	string	Trading pair	{"coin": {"values": ["BTC"]}}
side	string	"A" (ask) or "B" (bid)	{"side": {"values": ["B"]}}
px	string	Price level	-
sz	string	Size at level	-

Book Updates Filter Examples

// Get BTC bid updates only (WebSocket)
{"streamType": "book_updates", "filters": {"coin": ["BTC"], "side": ["B"]}}

// Get updates for multiple coins (WebSocket)
{"streamType": "book_updates", "filters": {"coin": ["BTC", "ETH", "SOL"]}}

Events Stream

Filter ledger updates including deposits, withdrawals, transfers, vault operations, and funding events.

Note: Events have nested structure with various types.

Field	Type	Description	Example Filter
users	array	Affected users	{"users": {"values": ["0x..."]}}
type	string	Event type	{"type": {"values": ["deposit", "withdraw"]}}
usdc	string	USDC amount	-
token	number	Token ID	{"token": {"values": ["124"]}}

Common Event Types:

deposit - USDC deposit
withdraw - USDC withdrawal
internalTransfer - Internal transfer
spotTransfer - Spot transfer
liquidation - Liquidation event
funding - Funding payment
vaultDeposit / vaultWithdraw - Vault operations

Events Filter Examples

// Get deposits only (WebSocket)
{"streamType": "events", "filters": {"type": ["deposit"]}}

// Get all events for a user (WebSocket)
{"streamType": "events", "filters": {"users": ["0xabc..."]}}

// Get vault operations (WebSocket)
{"streamType": "events", "filters": {"type": ["vaultDeposit", "vaultWithdraw"]}}

Writer Actions Stream

Monitor system actions including spot token transfers, perps operations, and core system activities.

Field	Type	Description	Example Filter
user	string	User address	{"user": {"values": ["0x200..."]}}
nonce	number	Action nonce	-
evm_tx_hash	string	EVM transaction hash	{"evm_tx_hash": {"values": ["0x..."]}}
action.type	string	Action type	{"type": {"values": ["SystemSpotSendAction"]}}
action.destination	string	Destination address	{"destination": {"values": ["0x..."]}}
action.token	number	Token ID	{"token": {"values": ["124"]}}
action.wei	number	Amount in wei	-

Common Action Types:

SystemSpotSendAction - Spot token transfer
SystemPerpsAction - Perps system action
CoreWriterAction - Core writer action

Writer Actions Filter Examples

// Get spot sends only (WebSocket)
{"streamType": "writer_actions", "filters": {"type": ["SystemSpotSendAction"]}}

// Get actions for specific token (WebSocket)
{"streamType": "writer_actions", "filters": {"token": ["124"]}}

// Get actions for specific user (WebSocket)
{"streamType": "writer_actions", "filters": {"user": ["0x200..."]}}

TWAP Orders Stream

Track Time-Weighted Average Price order status updates including running, completed, and cancelled TWAP orders.

Field	Type	Description	Example Filter
user	string	User address	{"user": {"values": ["0x..."]}}
coin	string	Trading pair	{"coin": {"values": ["BTC"]}}
side	string	"A" or "B"	{"side": {"values": ["B"]}}
status	string	TWAP status	{"status": {"values": ["running", "completed"]}}

MEMPOOL_TXS Stream (Testnet Only)

Monitor pending mempool transactions before block confirmation. Available only on Hyperliquid Testnet via gRPC.

Format: Each event is an array [timestamp, transaction_data]

Field	Type	Description	Example Filter
tx_hash	string	Transaction hash	{"tx_hash": {"values": ["0x450e9f..."]}}
type	string	Action type (order, noop, etc.)	{"type": {"values": ["order", "noop"]}}
a	number	Asset ID (for orders)	{"a": {"values": ["122", "6"]}}
b	boolean	Buy side (true=buy, false=sell)	{"b": {"values": ["true"]}}
p	string	Price (for orders)	-
s	string	Size (for orders)	-
r	boolean	Reduce only flag	{"r": {"values": ["true"]}}
c	string	Client order ID (optional)	{"c": {"values": ["0xf7d966..."]}}
nonce	number	Transaction nonce	-

MEMPOOL_TXS Filter Examples

// Get pending orders for specific asset (gRPC)
{"filters": {"type": {"values": ["order"]}, "a": {"values": ["122"]}}}

// Get buy orders only (gRPC)
{"filters": {"b": {"values": ["true"]}, "type": {"values": ["order"]}}}

// Get all order actions (gRPC)
{"filters": {"type": {"values": ["order"]}}}

StreamL2Book and StreamL4Book (OrderBookStreaming)

The StreamL2Book and StreamL4Book streams are part of a separate gRPC service (OrderBookStreaming) and use a different filtering model. Instead of the filter object syntax used by StreamData, these streams accept the coin directly as a request parameter:

// L2 - coin specified as a request field
L2BookRequest { coin: "BTC", n_levels: 20 }

// L4 - coin specified as a request field
L4BookRequest { coin: "ETH" }

Key differences from StreamData filtering:

gRPC only - StreamL2Book/StreamL4Book are not available via WebSocket or JSON-RPC
Same coin filtering capabilities - The node accepts the same coin parameters as StreamData

See the StreamL2Book and StreamL4Book dataset pages for full details.

Filter Limits

Three independent dimensions control what you can subscribe to. The same limits apply to both WebSocket and gRPC:

Concurrent streams - how many active streams you can run simultaneously. Plan-tiered.
Named filters per stream - how many filterName slots a single stream supports. Plan-tiered.
Filter values per field - how many values you can specify per field within one named filter. Server-side constants, the same for all plans.

See Plan Access & FAQ for the full limits table.

Limit error responses

Exceeding the field value cap returns -32602:

{
  "error": {
    "code": -32602,
    "message": "Filter validation failed: Too many values for field 'user': 101 (max: 100)"
  }
}

Exceeding the named-filter cap returns -32000:

{
  "error": {
    "code": -32000,
    "message": "Too many named filters per stream: 11 (max: 10)"
  }
}

Complete Examples

WebSocket Examples

Basic Subscription

// Subscribe to trades stream
{"jsonrpc":"2.0","method":"hl_subscribe","params":{"streamType":"trades"},"id":1}

// Response
{"jsonrpc":"2.0","result":{"subscribed":["trades"]},"id":1}

Filtered Subscriptions

// Filter trades by coin and side
{
  "jsonrpc": "2.0",
  "method": "hl_subscribe",
  "params": {
    "streamType": "trades",
    "filters": {
      "coin": ["BTC", "ETH"],
      "side": ["B"]
    }
  },
  "id": 1
}

// Get all liquidations
{
  "jsonrpc": "2.0",
  "method": "hl_subscribe",
  "params": {
    "streamType": "trades",
    "filters": {
      "liquidation": ["*"]
    }
  },
  "id": 1
}

// Get deposits for specific user
{
  "jsonrpc": "2.0",
  "method": "hl_subscribe",
  "params": {
    "streamType": "events",
    "filters": {
      "type": ["deposit"],
      "users": ["0xabc..."]
    }
  },
  "id": 1
}

// Get SystemSpotSendAction events
{
  "jsonrpc": "2.0",
  "method": "hl_subscribe",
  "params": {
    "streamType": "writer_actions",
    "filters": {
      "type": ["SystemSpotSendAction"]
    }
  },
  "id": 1
}

Unsubscribe

// Unsubscribe from specific filter
{"jsonrpc":"2.0","method":"hl_unsubscribe","params":{"filterName":"btc_trades"},"id":2}

// Unsubscribe from stream type
{"jsonrpc":"2.0","method":"hl_unsubscribe","params":{"streamType":"trades"},"id":3}

wscat One-Liners

Quick Testing Commands

# All trades (no filter)
wscat -c wss://endpoint/ws -w 9999
{"jsonrpc":"2.0","method":"hl_subscribe","params":{"streamType":"trades"},"id":1}

# BTC trades only
wscat -c wss://endpoint/ws -w 9999
{"jsonrpc":"2.0","method":"hl_subscribe","params":{"streamType":"trades","filters":{"coin":["BTC"]}},"id":1}

# Liquidations only
wscat -c wss://endpoint/ws -w 9999
{"jsonrpc":"2.0","method":"hl_subscribe","params":{"streamType":"trades","filters":{"liquidation":["*"]}},"id":1}

# Specific user's trades
wscat -c wss://endpoint/ws -w 9999
{"jsonrpc":"2.0","method":"hl_subscribe","params":{"streamType":"trades","filters":{"user":["0x123..."]}},"id":1}

gRPC Examples

gRPC Filter Examples

// JavaScript gRPC example
const request = {
  subscribe: {
    stream_type: 'TRADES',
    filters: {
      "coin": { values: ["BTC", "ETH"] },
      "side": { values: ["B"] }
    }
  }
};

// Python gRPC example
request = {
    "subscribe": {
        "stream_type": "TRADES",
        "filters": {
            "liquidation": {"values": ["*"]},
            "coin": {"values": ["BTC"]}
        }
    }
}

// Go gRPC example
request := &pb.SubscribeRequest{
    Subscribe: &pb.Subscribe{
        StreamType: pb.StreamType_TRADES,
        Filters: map[string]*pb.FilterValues{
            "coin": {Values: []string{"BTC", "ETH"}},
            "user": {Values: []string{"0x123..."}},
        },
    },
}

Response Format

Subscription Confirmation

{"jsonrpc":"2.0","result":{"subscribed":["trades"]},"id":1}

Stream Data

{
  "stream": "trades",
  "block_number": 817824278,
  "data": {
    "block_number": 817824278,
    "block_time": "2025-12-04T17:00:15.929034389",
    "local_time": "2025-12-04T17:00:16.076556955",
    "events": [
      ["0x727956612a8700627451204a3ae26268bd1a1525", {"coin": "HYPE", "side": "B", ...}]
    ]
  }
}

Important Notes

Case Sensitivity: Field names and values are case-insensitive ("Coin" = "coin" = "COIN", "btc" = "BTC")
Address Matching: Addresses are case-insensitive ("0xABC" = "0xabc")
Empty Filters: No filters = receive all events (no filtering applied)
Whitespace: Values are automatically trimmed of whitespace
Per-Stream Filters: Each stream can have independent filters
Recursive Matching: Filters search through nested JSON structures automatically
Tuple Format: TRADES stream uses [user, data] format; user filter matches the first element
Blocks Stream: The blocks stream does NOT support filtering (gRPC only, raw data)

Data Streams Overview - Learn about available data streams
gRPC API - gRPC streaming implementation
JSON-RPC API - WebSocket subscription methods
StreamL2Book - Aggregated depth via OrderBookStreaming (gRPC only)
StreamL4Book - Individual order book via OrderBookStreaming (gRPC only)

Overview​

Why Use Filtering?​

Basic Filtering Concepts​

Available Streams​

Filter Syntax​

Filter Logic​

AND Across Fields​

OR Within Field​

Combined Example​

OR Across Named Filters (Advanced)​

Recursive Field Matching​

Special Filter Values​

Stream-Specific Fields​

Trades Stream​

Orders Stream​

Book Updates Stream​

Events Stream​

Writer Actions Stream​

TWAP Orders Stream​

MEMPOOL_TXS Stream (Testnet Only)​

StreamL2Book and StreamL4Book (OrderBookStreaming)​

Filter Limits​

Complete Examples​

WebSocket Examples​

wscat One-Liners​

gRPC Examples​

Response Format​

Subscription Confirmation​

Stream Data​

Important Notes​

Related Documentation​
